Water Borehole Pneumatic Earth Drilling Equipment 260 Meters With Large Torque

Name: Water Borehole Pneumatic Earth Drilling Equipment 260 Meters With Large Torque
Brand: Shitan
Price: 1 USD

Buy cheap Water Borehole Pneumatic Earth Drilling Equipment 260 Meters With Large Torque product

Brand Name : Shitan

Model Number : ST 260

Certification : ISO

Place of Origin : Jinzhou ,Hebei Province

MOQ : 1 set

Price : Customzied Quotation list

Payment Terms : T/T,Western Union

Supply Ability : 2000 set/year

Delivery Time : 7-10 days

Packaging Details : 1*20 FCL

Product Name : ST 260 Large Pneumatic Drilling Rig

Drilling Depth : 260 meters

Drilling Hole Diameter : 305mm

Air Consumption : 16-55m³/min

Dimension : 4*1.7*2.2m

Lifting Force : 16 T

Weight : 6000kg

Drilling Rod Diameter : 76mm,89mm

Contact Now

Water Borehole Pneumatic Earth Drilling Equipment 260 Meters With Large Torque

High-Efficiency & Heavy-Duty Drilling Solution

Are you seeking a reliable, high-performance drilling rig for large-scale water borehole projects? The ST 260 Large Pneumatic Drilling Rig from Shitan Machinery delivers exceptional performance with a maximum drilling depth of 260 meters and robust 16-ton lifting force. This heavy-duty machine is engineered to tackle the toughest drilling conditions, providing consistent results for both commercial and industrial water well drilling applications.

Core Advantages

Exceptional Drilling Efficiency
Powerful & Stable Performance
Compact Design & High Maneuverability
Versatile Application Range

Technical Specifications

Product Name	ST 260 Large Pneumatic Drilling Rig
Brand	Shitan
Origin	Jinzhou, Hebei Province, China
Maximum Drilling Depth	260m
Walking Speed	2.5km/h
Footage Efficiency	10-35m/h
Air Consumption	16-55m³/min
Dimension (L×W×H)	4 × 1.7 × 2.2m
Lifting Force	16 T
Weight	6000kg
Drilling Rod Diameter	76mm
Working Wind Pressure	1.25-3.5 MPa
Drilling Hole Diameter	105-260mm
Climbing Speed	20 m/min

Why Choose Shitan ST 260 Pneumatic Drilling Rig?

Shitan has been a trusted name in the drilling industry for years, dedicated to producing high-quality, durable drilling equipment. The ST 260 is manufactured in our state-of-the-art facility in Jinzhou, Hebei Province, adhering to strict quality control standards to ensure reliability and longevity.

Professional Manufacturing
Customization Support
Comprehensive After-Sales Service

Application Scenarios

The ST 260 Large Pneumatic Drilling Rig is widely used in various water borehole drilling projects, including:

Commercial and industrial water supply well drilling
Agricultural irrigation well drilling
Residential community water well drilling
Geological exploration drilling in water-rich areas
Drilling projects in mountainous, hilly, and plain areas

Product Gallery

Water Borehole Pneumatic Earth Drilling Equipment 260 Meters With Large Torque

In operation at worksite

Drilling mechanism close-up

Side profile with dimensions

Control panel and operator station

Deep borehole drilling operation

Transport configuration

Drilling rod and bit assembly
